| ModelNo. | Size (inch) | Display Format | Touch Type | Brightness cd/㎡ | NTSC | Length*Width*Thickness (mm) | Active Area (mm) | AspectRatio | Interface | Backlight current voltage parameters | Temperature (°C) | Application | PDF Download |
| 9D-3R018-7159A | 1.78 | 368*448 | OLED | 315min/350typ | 90%(MIN),105%(TYP) | 35.45*43.95*2.114 | 28.4*34.94 | 3:4 | MIPI+SPI | - | -20℃~70℃ | Watch |  |
Full lamination of OLED and capacitive touch, total thickness ≤1.5mm for extreme slimness.
Supports 10-point touch, response <10ms, smooth gesture support like pinch-to-zoom and rotate.
OLED’s black-off feature allows touch wake-up in always-on mode to show time or notifications.
AF coating on cover reduces fingerprint smudges, keeping the screen clean.
Corning Gorilla Glass, hardness ≥8H, scratch-resistant – suitable for public touch terminals.
Touch controller has strong EMI immunity, stable operation near motors, inverters, and other strong interference sources.
Output via USB/I²C/SPI, compatible with Android/Linux/Windows – driver-free or standard drivers.
High-end smartwatches, automotive center consoles, portable medical diagnostic devices, handheld entertainment devices.
